1.Features of aluminum composite panel recycling machine

aluminum composite panel recycling machine

1With the aluminum composite panel recycling machine, the aluminum  and plastic can be completely separated for comprehensive utilization and to achieve a higher economic benefit and without dust and secondary pollution.

2. The aluminum and plastic separation and recycling can be completed under multicomputer controlled one time batch-feeding for crushing and automotive conveying, sound insulation and technology and cooling system.

3. Little noise, large output, innovative features. It can maintain the quality of the original aluminum besides recycle plastic. It can generate greater economic benefits for you.

4. It adopts high voltage electrostatic separation technology, higher metal recoveries, metal recycling rate of 98%.

5. This device also uses a triple dust device developed by our company, this dust removal device is composed of three dust collector: Cyclone dust, dust bag and air purifiers dust, can effectively solve the problem of dust pollution.



2.Technical data of aluminum composite panel recycling machine

Model	Voltage	Power	Capacity	Dimension	Weight
DYTM-400	380V	22.45 kw	150-200kg/H	2700*1900*2300(mm)	1200kg
DYTM-600	380V	36 kw	300-400kg/H	3500*1900*2700(mm)	3000kg
DYTM-800	380V	75 kw	500-600kg/H	5500*4500*3300(mm)	8000k

3.Application of aluminum composite panel recycling machine

Aluminum composite panel recycling machine can be widely used for separating various aluminum panels, waste aluminum plastic food bags, milk bags, toothpaste tubes, yogurt foil sealing lids, pharmaceutical blister foil, electrical circuit board, etc .



aluminum composite panel recycling machine appliable to this raw material
