Metal crusher is used cooperatively with waste tyre pyrolysis to fuel oil plant could processes the carbon black deeply and raise the value of the carbon black.

Chat Online Leave A Message
metal crusher
metal crusher

1. Comparing with the Raymond mill, this metal crusher is assembled with pressurized spring to improve the mill eiciency. its capacity increases by 10%-20% under the same power condition, and compression force of rollers to material improve 800-1200kgf under the force of high-pressure spring.

2. Metal crusher are made of high quality hard alloy and is wear resisting. Customers also can choose other high abrasive materials, such as 65Mn, Mn13Cr2Cr and chrominum cast steel, according to the actual material.

3. High quality speed regulating motor is adopted to adjust the rotation speed of analyzer, and the output size also can be adjusted accordingly.  The variable frequency motor also can be used.

4. Blade analyzer is adopted to analysis the powder of 0-400 mesh effectively.
Model 3R1410 3R1815 3R2115 3R2615 3R2715 3R3016 4R2715 4R3016 4R3216 5R4119 6R4427
(mm)Max Feeding Size 10-15 10-15 10-15 15-20 15-20 20-25 15-20 20-25 20-25 20-30 20-50
(mm)Output Size 0.250-0.045mm/60-325mesh
(T)Capacity 1-10 1.3-14 1.5-16 41694 2-29 3-34 2-31 3-35 3-39 5-66 10-140
(r/min) Centre Axis Speed 280 195 160 162 162 160 162 160 140 103 82
(mm)Grinding ring Outer Dia. 500 630 725 861 915 975 915 975 1073 1400 1750
(mm)Grinding roller Dia. 140 180 210 260 270 300 270 300 320 410 420
(mm)Roller and ring height 100 150 150 150 150 160 150 160 160 190 270
(kw)Main Motor  7.5 11 15 18.5 22 30 22 30 37 75 132
(kw)Blower Motor Power 5.5 7.5 11 18.5 18.5 22 18.5 22 30 75 132
(kw)Analyzer Motor Power 1.1 1.5 2.2 2.2 2.2 2.2 2.2 2.2 5.5 7.5 11
