Continuous Tyre Pyrolysis plant

Along with the world economy progressing development, the oil resource scarce tendency has grown up day by day, enters into the 90's, the energy has become the primary factor that restricts various countries economy development. While, at the same time, energy waste can be seen everywhere. Seeking the new energy has become the various countries’ matter of concern. Henan Doing Group company is the leading domestic professional manufacturer in Convert plastic waste to fuel oil machine, waste tyre recycling eqipment, waste engine oil distillation machine. Our final principle is to clean the world and renew waste to energy, welcome all strategic friends join us!

• Ms. Bonnie Zhao
• +86-371-5677 1821
• +86 158 9380 0169
• Skype:bonniezhao2
• oilmachine@doinggroup.com

• Features
• Technical Data
• Application

Convert plastic waste to fuel oil machine:
Along with the world economy progressing development, the oil resource scarce tendency has grown up day by day, enters into the 90's, the energy has become the primary factor that restricts various countries economy development. While, at the same time, energy waste can be seen everywhere. Seeking the new energy has become the various countries’ matter of concern. Henan Doing Group company is the leading domestic professional manufacturer in Convert plastic waste to fuel oil machine, waste tyre recycling eqipment, waste engine oil distillation machine. Our final principle is to clean the world and renew waste to energy, welcome all strategic friends join us!


Convert plastic waste to fuel oil

DY-D2800mm*L6600mm
1. With the help of the auto-feeder, the reactor of waste to fuel oil machine can to contain 12 tons crushed tire or 10 tons whole tyre.
2. I f the raw materil is waste plastic, it can contain even 12 tons if you use the right feeding way.
3. The diameter of the reactor feeding door is 1200mm.
4. After 2 hours' feeding time, it's time to heat the reactor by coal/wood/natural gas or fuel oil. Generally speaking, when the temperature reaches to 155 Celsius degrees around, the oil gas will generated.

• Technical Data

Technical parameter of  convert plastic waste to fuel oil machine
	Items	Contents
1	Equipment type	DY-1-6	DY-1-8	DY-1-10
2	Raw material	Waste plastic	waste plastic	waste plastic
3	Structural form	Horizontal rotation	Horizontal rotation	Horizontal rotation
4	24-hour Capacity	6 ton	8 ton	10 ton
5	Oil yield	2.7-3.3ton	3.6 -4.4ton	4.5 -5.5ton
6	Operating pressure	Normal	Normal	Normal
7	Material of Reactor	Q245R	Q245R	Q245R
8	Thickness of Reactor	16mm	16mm	16mm
9	Rotate speed	0.4turn/minute	0.4turn/minute	0.4turn/minute
10	Total power	19KW	19KW	19KW
11	Mode of cooling	Water cooling	Water cooling	Water cooling
12	Cooling area	100sqm	100sqm	100sqm
13	Kind of transmission	Internal gear drive	Internal gear drive	Internal gear drive
14	Noise dB(A)	≤85	≤85	≤85
15	Size of Reactor(D×L)	2200×6000	2200×6600	2600×6600
16	Working form	Intermittent operation	Intermittent operation	Intermittent operation
17	Delivery time	20days	20days	20days
18	Weight	27T	30T	35T

• Application

                              Fuel oil application range

Now, more and more people know this project, and DOING GROUP Convert plastic waste to fuel oil machine used by waste tyre and plastic recycling companies with owned a good reputation around the world.
Project Case:
Albania, Italy, Poland, Romania, Pakistan, Mexico, Haiti, Iran, Malaysia, Ecuador, India, etc.
